CPU : AMD AM5 RYZEN 7 7700 3.8GHz #3Y

🟢SPECIFICATIONS

Name : AMD Ryzen™ 7 7700

Family : Ryzen

Series : Ryzen 7000 Series

Form Factor : Desktops , Boxed Processor

Market Segment : Enthusiast Desktop

AMD PRO Technologies : No

Regional Availability : Global

Former Codename : Raphael AM5

Architecture : Zen 4

# of CPU Cores : 8

Multithreading (SMT) : Yes

# of Threads : 16

Max. Boost Clock  : Up to 5.3 GHz

Base Clock : 3.8 GHz

L1 Cache : 512 KB

L2 Cache : 8 MB

L3 Cache : 32 MB

Default TDP : 65W

Processor Technology for CPU Cores : TSMC 5nm FinFET

Processor Technology for I/O Die : TSMC 6nm FinFET

CPU Compute Die (CCD) Size : 71mm²

I/O Die (IOD) Size : 122mm²

Package Die Count : 2

Unlocked for Overclocking  : Yes

AMD EXPO™ Memory Overclocking Technology : Yes

Precision Boost Overdrive : Yes

Curve Optimizer Voltage Offsets : Yes

AMD Ryzen™ Master Support : Yes

CPU Socket : AM5

Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

CPU Boost Technology : Precision Boost 2

Instruction Set : x86-64

Supported Extensions : AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus ,

SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

Thermal Solution (PIB) : AMD Wraith Prism

Max. Operating Temperature (Tjmax) : 95°C

Launch Date : 01/14/2023

*OS Support : Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
